Mounting Turbimax CUS51D
20 Endress+Hauser
Immersion operation
Fixed installation with wastewater assembly
1
2
3
4
A0013383
 16 Installation on railing
1 Turbimax CUS51D turbidity sensor
2 Wastewater assembly Flexdip CYA112
3 Transverse pipe, Flexdip CYH112 holder
4 Main pipe, Flexdip CYH112 holder
1
2
3
4
5
6
A0051207
 17 Installation with upright post
1 Main pipe, Flexdip CYH112 holder
2 Liquiline CM44x multi-channel transmitter
3 Weather protection cover
4 Transverse pipe, Flexdip CYH112 holder
5 Wastewater assembly Flexdip CYA112
6 Turbimax CUS51D turbidity sensor
