L: AC phase power supply.
N: Neutral AC power supply.
S1: Left terminal: AC phase supply.
Right terminal: NC motor output (right rotation)
S2: Left terminal: NC motor output (left rotation)
Right terminal: AC power supply phase.
K1: Switch line input for S1
K2: Switch line input for S2
