Part list – CT 12.5 Ergometer - 2010
Nr. Description Size Qty Nr. Description Size Qty
1 BASE FRAME 1 41 FIX HANDLEBAR FOAM GRIPS Ø20.0 2
2 FRONT FOOT 1 42 FRONT FOOT COVER(L) 1
3 REAR FOOT 1 43 FRONT FOOT COVER(R) 1
4 HANDLEBAR POST 1 44 REAR FOOT COVER 2
5 SADDLE POST 1 45 ROUND SCREW FOR ADJ HEIGH M10 2
6 MOVABEL SEAT POST 1 46 PLASTIC BUSH 2
7 FIX PLATE 1 47 HANDLEBAR CAP 2
8 HANDLEBAR 1 48 SADDLE SUPPORT TUBE INSERT 1
9 BRACKET 1 49 MOVABEL SEAT POST KNOB 3/8"*16 1
10 CROSS FRAME (L) 1 50 SEAT KNOB 1
11 CROSS FRAME (R) 1 51 KNOB M8 1
12 EMS BRAKE
Ø242.7
1 52 BELT 6PJ440 1
13 AXLE FOR PULLEY 1 53 REAR PULLEY Ø250 1
14 HEX HEAD BOLT M8*25 1 54 PEDAL (L / R) JD-22A 1
15 ALLEN HEAD SCREW M8*15 8 55 PLASTIC CAP 2
16 HEX HEAD BOLT M6*18 4 56 TURNUNG PLATE COVER 2
17 HEX HEAD BOLT M6*14 8 57 BACK HANDLEBAR COVER 1
18 SCREW M5*12 14 58 FRONT HANDLEBAR COVER 1
19 SCREW M3*12 2 59 SADDLE A16 1
20 SCREW M5*10 2 60 CHAIN COVER ( L ) 1
21 CARRIAGE BOLT M8 * 52 2 61 CHAIN COVER ( R ) 1
22 SCREW M5*15 2 62 TURNING PEDAL 1
23 SCREW M5*12 2 63 CUP FOR SEAT POST 1
24 SCREW M5*15 4 64 SADDLE POST COVER 1
25 SCREW #6-32 *12L 3 65 COMPUTER TZ-6152 1
26 M8 WASHER M8 10 66 CONTROLLER 1
27 M6 WASHER M6*1.2 8 67 PULSE GRIP NUIT 2
28 M8 WASHER M8*1.2 1 68 SENSOR BRACKET 1
29 WASHER Ø17* 0.3 1 69 MAGNET 1
30 M10 WASHER M10 *2 1 70 ADAPTOR 1
31 NYLONT WASHER Ø10*0.3 1 71 COMPUTER UPPER CABLE 1
32 M8 SPRING WASHER M8 10 72 COMPUTER LOWER CABLE 1
33 M6 SPRING WASHER M6 12 73 SENSOR 1
34 CLIP C17 C17 3 74 DC CABLE 1
35 NYLOCK NUT M8 M8 2 75 HAND PULSE WIRE 1
36 NYLOCK NUT M6 M6 4 76 MOTOR LUNK 1
37 BUSHING 1 77 TOOL 1
38 SCREW CAP M8 3/8" 2 78 TOOL 1
39 BEARING 6203ZZ 4 79 PLASTIC BUSH 1
40 CARGE SPRING 1
