PARTS LIST PR 5.9 - 2012
Description Qty.
418
Soft drop shock holder foot locker 1
419 Spring 1
422
Nylon25.6X25X41.6XR17 4
423 Elevation support tube fix holder 2
424 Incline motor travel fix Pin 1
428 Electric Outlet 1
429 Electric Protector 1
430 Power Switch 1
500 Motor cover and Motor
501
Motor hood cover 1
502
Motor hood decorate strip-Right 1
503 Motor hood decorate strip-Left 1
504 Motor Front Cover 1
505 Motor hood decorate cover –Right 1
506 Motor hood decorate cover –left 1
507 Motor 1
508 Driving belt 1
509 Motor holder 1
511 Spring pieces 21X13X0.7 2
512 EVA Foam sticker 6
600 Wire Assembly.
608 White two female wire 1
609 Ground connect wire 1
610 Red two female power cable 2
611 White two female power cable 1
612 Hand pulse wire 2
613 Blue/Grey power wire 1
614 Red /black elevation motor connect wire 1
617 6 PIN computer connect wire 1
700 Running deck and belt
701 Deck Frame 1
703 Front Roller Tube+Shaft 1
704
Rear Roller Tube+Shaft 1
705
Main frame cross bar 1
706 Main frame cross bar Foam 15XL300XT3.5 1
707 Base frame crash cushion OD30X25 2
708 Rear Caster 2
709 Move positioning micro switch 2
710 Isolator 2
714 Transformer 1
715 Control board 1
720 Side rail 2
721 Side rail decorate strip 2
723 Running deck 1
724 Rear cap –left 1
725 Rear cap-right 1
726 Side rail guider 8
