Enerpac RSL2 - Hexagon Cassette Dimensions (Imperial)

24
RSL Torque Wrench
7.2 Additional Hexagon Cassette Specifications
7.2.1 Imperial System Table - RSL Hexagon Cassette
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size inch
(Max)
(R)
inch
(L)
inch
(H)
inch
(W)
inch
Weight
lbs
RLP1 (to be used with Torque Wrench Drive RSL1500)
RLP1014
7
/8
0.79 6.00 1.25 4.33 2.2
RLP1101 1
1
/16 0.95 6.05 1.25 4.50 2.2
RLP1102 1
1
/8 1.03 6.12 1.25 4.57 2.3
RLP1103 1
3
/16 1.03 6.12 1.25 4.57 2.3
RLP1104 1
1
/4 1.03 6.12 1.25 4.57 2.3
RLP1105 1
5
/16 1.15 6.24 1.25 4.69 2.4
RLP1106 1
3
/8 1.15 6.24 1.25 4.69 2.4
RLP1107 1
7
/16 1.15 6.24 1.25 4.69 2.4
RLP1108 1
1
/2 1.31 6.41 1.25 4.86 2.7
RLP1109 1
9
/16 1.31 6.41 1.25 4.86 2.7
RLP1110 1
5
/8 1.31 6.41 1.25 4.86 2.7
RLP1111 1
11
/16 1.40 6.49 1.25 4.94 2.7
RLP1112 1
3
/4 1.40 6.49 1.25 4.94 2.7
RLP1113 1
13
/16 1.40 6.49 1.25 4.94 2.7
RLP1114 1
7
/8 1.48 6.58 1.25 5.03 2.7
RLP1115 1
15
/16 1.48 6.58 1.25 5.03 2.7
RLP1200 2 1.48 6.58 1.25 5.03 2.7
RLP1201 2
1
/16 1.58 6.68 1.25 5.13 2.7
RLP1202 2
1
/8 1.58 6.68 1.25 5.13 2.7
RLP1203 2
3
/16 1.58 6.68 1.25 5.13 2.7
RLP1204 2
1
/4 1.70 6.79 1.25 5.24 2.8
RLP1205 2
5
/16 1.70 6.79 1.25 5.24 2.8
RLP1206 2
3
/8 1.70 6.79 1.25 5.24 2.8
RLP3 (to be used with Torque Wrench Drive RSL3000)
RLP3105 1
5
/16 1.18 7.62 1.38 5.49 3.5
RLP3106 1
3
/8 1.18 7.62 1.38 5.49 3.5
RLP3107 1
7
/16 1.18 7.62 1.38 5.49 3.5
RLP3108 1
1
/2 1.32 7.77 1.38 5.63 3.9
RLP3109 1
9
/16 1.32 7.77 1.38 5.63 3.9
RLP3110 1
5
/8 1.32 7.77 1.38 5.63 3.9
RLP3111 1
11
/16 1.47 7.87 1.38 5.78 4.0
RLP3112 1
3
/4 1.47 7.87 1.38 5.78 4.0
RLP3113 1
13
/16 1.47 7.87 1.38 5.78 4.0
RLP3114 1
7
/8 1.60 8.04 1.38 5.92 4.5
RLP3115 1
15
/16 1.60 8.04 1.38 5.92 4.5
RLP3200 2 1.60 8.04 1.38 5.92 4.5
RLP3201 2
1
/16 1.76 8.16 1.38 6.08 4.7
RLP3202 2
1
/8 1.76 8.16 1.38 6.08 4.7
RLP3203 2
3
/16 1.76 8.16 1.38 6.08 4.7
RLP3204 2
1
/4 1.84 8.25 1.38 6.15 4.8
RLP3205 2
5
/16 1.84 8.25 1.38 6.15 4.8
RLP3206 2
3
/8 1.84 8.25 1.38 6.15 4.8
RLP3207 2
7
/16 1.95 8.14 1.38 6.26 4.6
RLP3208 2
1
/2 1.95 8.14 1.38 6.26 4.6
RLP3209 2
9
/16 1.95 8.14 1.38 6.26 4.6
RLP3210 2
5
/8 2.04 8.23 1.38 6.36 4.4
RLP3211 2
11
/16 2.04 8.23 1.38 6.36 4.4
RLP3212 2
3
/4 2.04 8.23 1.38 6.36 4.4
RLP3213 2
13
/16 2.16 8.34 1.38 6.54 4.7
RLP3214 2
7
/8 2.16 8.34 1.38 6.54 4.7
RLP3215 2
15
/16 2.16 8.34 1.38 6.54 4.7
