ENFORCER SECO-LARM SL-126Q User Manual

ENFORCER Strobe Lights
2 SECO-LARM U.S.A., Inc.
Circuits All solid-state
Input connections Red: positive, black: negative
Leads 18-gauge UL listed, 12" long
Electrical protection Reverse polarity protected
Illumination 100,000 candle power
Operating voltage 6~12 VDC
Current draw (max.) 200mA@12VDC
Flash rate Over 60/minute at 6VDC, Over 90/minute at 12VDC
Operating life (flashes) Over 2,000,000 flashes
Operating life (hours) 450@6VDC, 300@12VDC
Operating temperature -22°~140° F (-30°~60° C)
Material
Base High-impact black ABS
Lens
High-impact and heat-resistant acrylic
Available in clear, amber, green, red, and blue
Features:
Overview:
Specifications:
2
15
/
16
"
(74 mm)
7
/
8
"
(
22 mm
)
2
1
/
16
"
(52 mm)
12"
(
305 mm
)
Drill two
1
/
16
"
(2.3mm) holes for
mounting screws
(included)
2
3
/
16
"
(71 mm)
Top Side Bottom
Please read the manual before you begin the installation.
 For "informative" general signaling
requirement applications
 Powerful xenon tube makes flash visible from
a distance
 Reverse polarity protection
 Operating life of over 300 hours
 Temperature range from -22°~140° F
(-30°~60° C)
 Case is made of high-impact resistant ABS
plastic, with an approx. diameter of 4" (10cm)
 Lens is made of high-impact and heat-resistant
acrylic. Available in clear, amber, green, red, or
blue (Also available separately)
 Heavy-duty 18-gauge leads
 Five lens colors available:
SL-126Q/A — Amber lens
SL-126Q/B — Blue lens
SL-126Q/C — Clear lens
SL-126Q/R — Red lens
SL-126Q/G — Green lens
ø3
15
/
16
"
(ø100 mm)

ENFORCER SECO-LARM SL-126Q Specifications

General

Brand	ENFORCER
Model	SECO-LARM SL-126Q
Category	Lighting Equipment
Language	English
