ENGEL
BATTPAK
28 & 56 AMP HOUR
The Engel Battpak is a portable deep cycle
dual battery system for powering your
Engel Portable Fridge - Freezer and
Accessories, in & out of your
vehicle.
• The BATTPAK is designed for use
primarily with the range of ENGEL
portable fridge/freezers, but can be
used with almost all portable
fridge/freezers and a large variety of
12 volt appliances.
• The BATTPAK is designed to be charged
via the 12 volt charge lead supplied.
• Press the MOMENTARY button on the
control panel of the BATTPAK and the volt
gauge will indicate its state of surface charge.
• The BATTPAK is a maintenance-free rechargeable
sealed lead-acid battery.
• Your BATTPAK will operate in any direction or position
without leakage and at temperatures between -20
o
c &
+50
o
c.
• The BATTPAK 28 has 2 Outlets. One 12 Volt Cigar
plug, and one ENGEL POSI FIT Socket.
• The BATTPAK 56 has 3 Outlets. One 12 Volt Cigar
plug, one Hella plug and one ENGEL POSI FIT Socket.
• All Outlets are fitted with ON/OFF rocker switches and
are fused at 15 Amps.
• The BATTPAK should always be recharged after use.
• The BATTPAK batteries have a life of between 300 and
400 charge cycles.
MOMENTARY BUTTON
Green 13V to 13.4V Fully Charged
Orange 9V to 13V Normal
Red 0V to 9V Requires Charging
OPTIONAL ACCESSORIES: 12VDCBATTCHARGER
The Engel 12VDCBattcharger is an electronic battery
charger designed to charge Lead Acid Batteries from a 12
volt DC Battery. The charger uses a unique boost charge
feature, stepping up to a charge rate allowing the
auxiliary battery to properly charge and with its voltage
sensing feature ensuring the main battery charge is not
depleted while the vehicle is not running. The12VDC
Battcharger will charge your BATTPAK at up to 10 Amps.
CHARGING FROM CHARGE LEAD SUPPLIED
The LED will flash when charging is in progress and
will TRICKLE charge your BATTPAK at approximately 2 to
4 Amps. The rate of charge will drop as the level of
charge increases.
CHARGING WITH 240 VOLT / SOLAR PANELS
We recommend a 6 to 8 Amp Automatic (floating and
regulated) type 240 Volt mains battery charger. You will
need to purchase a male single pole Hella plug to
replace the alligator clips supplied with the battery
charger, making sure the red lead is positive and the
black is negative. Solar Panels can be used to charge
your BATTPAK but must be regulated, with a maximum
output of 8 Amps.
MODEL BATTPAK28 BATTPAK56
Height 285mm 285mm
Width 190mm 190mm
Depth 200mm 380mm
Weight 14kg 26kg
