- 16 -
Battery monitor setting
OFF
-
-
-
-
LO
10.5V
11.5V
21.0V
23.1V
HI
11.5V
12.5V
23.1V
25.0V
Cut out Voltage
Cut in Voltage
Cut out Voltage
Cut in Voltage
12V
12V
24V
24V
Fig.4
CAUTION
To avoid damage to the refrigerator in the event of reverse
polarity or short circuit, install a 10A fuse in the wiring circuit
nearer to the battery.
10A FUSE
