Physical Interface - ENS500-ACv2/ENS500EXT-ACv2
Dimensions
Length: 186 mm (7.32”)
Width: 100 (3.94”)
Depth: 29mm (1.14”)
1 5 GHz Antennas Detachable5dBi5GHzOmni-directionalAntennas
(ENS500EXT-ACv2 Only)
2 LAN Port 1 (Proprietary24V PoE): Ethernet port for RJ-45 cable.
3 LAN Port 2 : Ethernet port for RJ-45 cable.
4 LED Indicators: LED lights for Power, LAN Port 1, LAN Port 2, 2.4
GHzConnectionand5GHzConnection.
5 Mounting Holes: Using the provided hardware, the AP can be
attached to a wall or pole.
*The installation angle of antenna must be vertical to the ground.
4
1
23
1
5
Physical Interface - ENS500-ACv2/ENS500EXT-ACv2
Dimensions
Length: 260mm (10.24”)
Width: 84 (3.31”)
Depth: 55mm (2.17”)
1 LAN Port 1 (Proprietary24V PoE): Ethernet port for RJ-45 cable.
2 LAN Port 2 : Ethernet port for RJ-45 cable.
3 Reset Botton
*The installation angle of antenna must be vertical to the ground.

EnGenius EnStationACv2 Specifications

General

Brand	EnGenius
Model	EnStationACv2
Category	Wireless Access Point
Language	English
