5
ISWITCH MULTIBOX OFF LINE
Characteristics
Reference: DEMTxABA0S
Description: iSWITCH multibox RFID OFF LINE energy saver
Power source: 110 -230 VAC
Energy consumption: Nominal 30 mA, Maximum 50 mA (230 VAC)
Frequency 50 – 60 Hz.
Output relays: 2 relays. One according to net voltage and the other
one free voltage.
Cutting power: 12 A, 230 V~, cos =1
8 A, 230 V~, cos = 0.6
Maximum incandescent load 10 A.
Maximum halogen load 10 A.
Dimensions: BUILT-IN SYSTEM: Height 80 mm, width 80 mm and
depth 15.5mm
SURFACE SYSTEM: Height 80 mm, width 80 mm and
depth 32mm
Weight: 104 grammes.
Housing: Fireproof ABS material (according to UL94V-0 standard)
Pilot lights: 2 different coloured lights (red and green)
Operating temperature: 0º - 50º
