4.5.5. PEDAL INSTALLATION
• Take the pedals out of the box
• Apply a small amount of grease to the screw portion of
the pedal
• Look for the letters displayed on the head of the screw
“L” indicates left, and “R” indicates right Figure 4L
• Tighten the pedals using a size 15mm wrench
• Tighten the right pedal in a clockwise motion Figure 4M
• Tighten the left pedal in an anti-clockwise motion
4.5.6. SADDLE INSTALLATION
• Apply some grease to the seat tube
• Insert the seat post into the tube Figure 4N
• Adjust to preferred height
• Tighten the seat clamp
Figure 4L
Figure 4M
Figure 4N
