12TI0075 - Expanse Table Installation Instructions
Levelers are accessible through the
access hole on the tops of the base.
Place a level spanning both beams and
level the table across it’s depth.
Install the Outside Base Bottom
Covers between the Base legs.
Place a level on the beam between the 2
bases and level the table length rst.
7.1
7.3 7.4
7.2
7 — LEVELING
2x
