SPECIFICATION
Power Handling:
100 Watt speech and music
Frequency Response:
65 Hz - 20 kHz
Impedance:
8 Ohm nominal
Sensitivity:
87dB/1w/1m
Amplifier Compatibility:
25 - 100 Watt
Positioning:
Either above or below the CRT or
Plasma monitor. If close to the
floor, angle the speaker up a little to
aim at listener’s face.
Bass/Midrange Driver:
2 x 130 mm polymer cone with
25mm high temperature voice coil,
injection moulded PP cone
mounted on an inert die-cast
aluminium chassis
Tweeter:
25 mm aluminium dome with high
temperature voice coil and
neodymium shielded magnet
system
Crossover:
Bass driver crossover is achieved
by 4 components in a 2nd order
filter & tweeter uses 4
components in a 3rd order filter at
3 kHz crossover
Cabinet:
12 mm HD Chipboard wrap and
25mm MDF front baffle with vinyl
wood finish
Finish:
Light Cherry, Dark Cherry, or
Black Ash.
Size:
174(H) x 510(W) x 210(D)
7 x 20 x 8.25 in.
Weight:
8.8 kg / 19 lb
10.5 Kg / 21 lb (boxed)
Centre Channel
