Rigging at the Beach
1. Place the wireless controller on your wrist and secure snuggly
with the Velcro strap.
2. Tip your board onto its rail, pull the pin from the motor shaft,
and insert the motor wire and shaft through the board. Reinstall
the pin making sure it goes through the hole in the deck adaptor
plate and that the propeller portion of the motor is aft. There is
a white mark on the shaft indicating the aft side of the motor.
Secure the pin in place with the retainer clip. When installed
properly, the motor is secured to the adaptor by the pin and the
motor is oriented to propel the board forward.
3. Put your board in the water and attach the motor to the
battery by twisting the collar clockwise. Be careful not to over-
tighten the collar and not to cross-thread the connector.
4. Place the battery on the Velcro located on the deck of your
board and slip the bungees over the battery for additional
security.
5. Kneel on the board with your paddle in one hand. Press the
battery activation button and hold until all LED lights are
flashing. On the wireless controller, ensure the speed bar is in
the off position (away from the button). A quick press of the
controller button will pair the controller with the battery. When
paired, all four LED lights on the battery will steadily illuminate
indicating your battery has a full charge and the drive system is
activated.
6. Check your surroundings for potential hazards. When clear,
start the motor by sliding the speed bar on the controller to the
desired speed. After a two second delay, the motor with ramp
up to speed. Once moving, standup and begin to paddle.
