Confidential
Disassembly/Reassembly Overview 13
Epson WorkForce 635/625/60 series Revision E
1.1.2 Jigs
Note *: The required tools differ between WorkForce 635 series, WorkForce 625 series and WorkForce 60 series. Be careful not to mix
up the tools.
Name Q’ty EPSON Part Code
Paper guide front supporting tool (A)* 1 WorkForce 635 series: 1543170
WorkForce 625 series: 1543171
WorkForce 60 series: 1543170
Paper guide front supporting tool (B)* 1 WorkForce 635 series: 1543539
WorkForce 625 series: 1543544
WorkForce 60 series: 1543539
Paper guide front supporting tool (C)* 3 WorkForce 635 series: 1543541
WorkForce 625 series: 1543547
WorkForce 60 series: 1543541
Printhead supporting tool 2 1543169
