6 - 62
Chapter 6 Principles of Operation
Epson AcuLaser C2900N
Revision B
Confidential
FRONT
MiS06039KA
: Indicates the engagement of gears.
[ Name of moving parts ]
[ DEVELOPMENT DRIVE ]
DRIVE ASSY SUB
Drum Cartridge
GEAR MAG
GEAR MAG IDLR
GEAR IDLER PADDLE
GEAR PADDLE
GEAR AUGER
GEAR AUGER
HSG ASSY DEVE
[ MAGNET ROLL ]
[ AUGER REAR ]
[ AUGER FRONT ]
[ PADDLE DEVE ]
