EPSON AcuLaser C9200N Revision D
OPERATING PRINCIPLES Operating Principle of Main Unit Mechanism 55
Confidential
2ND IMAGE TRANSFER SECTION
Figure 2-32. Composition
4038T2C019DA
4038T2C106AA
4038T2C152AA
Temperature/Humidity Sensor (SE3)
2nd Transfer Roller
Temperature/Humidity Sensor
(SE3)
IDC/Registration Sensor /1 (SE1)
IDC/Registration Sensor /2 (SE2)
4038T2C117AA
4039T2C11AA
2nd Transfer Roller
2nd Image Transfer Pressure
Position Sensor (PC7)
2nd Image Transfer Pressure/
Retraction Motor (M5)
IDC/Registration Sensor /1 (SE1)
IDC/Registration Sensor /2 (SE2)
Shutter
Shutter
