13. Close cover B.
Paper Jam C2, C3, C4, E2, E3, B (Cassette2-4, Cover E2-E3, Cover B)
Note:
Be sure to open and close cover B in the last step of the following procedure even if there is no jammed
paper inside cover B.
The instruction describes about optional lower paper cassette C2 as an example. Use the same
procedure for optional paper cassette C3 and C4.
1. Pull out the optional paper cassette from the cassette unit.
AL-M300/AL-M400 Series User's Guide
Troubleshooting 145
