4:3

16:9

Projecting images from the HDMI or DisplayPort ports (for EB-1960/EB-1950/

EB-1930)

Each time the Aspect button is pressed, the aspect mode changes in the

order Normal or Auto, 4:3, and 16:9.

Example: 1080p signal input (resolution: 1920x1080, aspect ratio: 16:9)

Normal or Auto

4:3

16:9

Projecting images from a computer

The following shows projection examples for each aspect mode.

For EB-1940W

Aspect Mode Input Signal

XGA 1024X768(4:3) WXGA 1280X800(16:10)

Normal

16:9

Full

Zoom

Native

Adjusting Projected Images
