Epson EB-485Wi Installation Guide

12
The smallest screen size is 56".
The smallest screen size is 60".
The smallest screen size is 53".
EB-480i/480/470 (4:3 aspect ratio)
[Unit: cm]
S a b c h
Interactive Whiteboard
Screen Size Projection
Distance
Minimum
(Wide) to
Maximum
(Tele)
Numbers on
the slider
measure
Distance
Between
Projection
Surface
and Wall
Plate
Height of
Projection
Surface
56" 113.9 x 85.3 6.3 - 19.3 12.5 - 25.5 15.2 85.3
57" 115.8 x 86.9 6.9 - 20.2 13.1 - 26.4 15.4 86.9 PolyVision TS410
60" 122.0 x 91.4 8.9 - 22.9 15.1 - 29.1 16.1 91.4 HitachiCambridge board60
RM Classboard 60
INTERWRITE
®
BOARD 1060
INTERWRITE Dual board 1260
63" 128.0 x 96.0 10.9 - 25.6 17.1 - 31.8 16.9 96.0 Hitachi Starboard FX DUO 63
64" 130.0 x 97.5 11.6 - 26.5 17.8 - 32.7 17.1 97.5 SmartBoard660
ActivBoard 164
66" 134.2 x 100.6 12.9 - 28.3 19.1 - 34.5 17.6 100.6 TeamBoard RT TMWM5422CL/
EM
69" 140.3 x 105.2 14.9 - 30.7 21.1 - 36.9 18.3 105.2
EB-485Wi/485W/475Wi/475W (16:10 aspect ratio)
[Unit: cm]
S a b c h
Interactive Whiteboard
Screen Size Projection
Distance
Minimum
(Wide) to
Maximum
(Tele)
Numbers on
the slider
measure
Distance
Between
Projection
Surface
and Wall
Plate
Height of
Projection
Surface
60" 129.3 x 80.8 6.2 - 19.3 12.4 - 25.5 17.4 80.8
69" 148.6 x 92.9 11.8 - 26.8 18.0 - 33.0 19.8 92.9
EB-480i/480/470 (16:10 aspect ratio)
[Unit: cm]
S a b c h
Interactive Whiteboard
Screen Size Projection
Distance
Minimum
(Wide) to
Maximum
(Tele)
Numbers on
the slider
measure
Distance
Between
Projection
Surface
and Wall
Plate
Height of
Projection
Surface
53" 114.1 x 71.3 6.4 - 19.5 12.6 - 25.7 22.3 71.3
60" 129.3 x 80.8 11.3 - 26.1 17.5 - 32.3 25.1 80.8
69" 148.6 x 92.9 17.7 - 30.7 23.9 - 36.9 28.7 92.9
