Epson EB-485Wi Installation Guide

24
(3) Secure the setting plate to the wall plate by tightening the supplied M6 x 20 mm cross
recessed head shoulder screws (x3) with the No.3 cross-head screwdriver ( ).
(4) Loosely tighten the M6 x 20 mm hexagon shoulder bolt supplied ( ).
M6 x 20 mm cross recessed
head shoulder screws (x3)
M6 x 20 mm hexagon shoulder bolt
Spring washer
Washer
