Epson EB-520 User Manual

Notations Used in This Guide ........................ 2
Introduction
Projector Features .......................................... 8
Quick and Easy Set up, Projection, and Storage..........................8
Connecting with a USB Cable and Projecting (USB Display)................8
Useful Functions for Projecting Images................................8
Connect a USB Storage Device and Project Movies or Images (PC Free) . . . . . . . . 8
Flip the Image Horizontally and Project (Flip Horizontal)..................8
Various Functions for Excellent Power Saving......................... 8
Making the Most of the Remote Control .............................8
Enlarge and Project Your Files with the Document Camera................9
Enhanced Security Functions....................................9
Taking Full Advantage of a Network Connection.........................9
Interactive Features (Easy Interactive Function) (EB-536Wi only)..............10
Part Names and Functions .................................. 11
Front/Top ...................................................11
Rear.......................................................12
Base ......................................................14
Control Panel................................................15
Remote Control...............................................16
Replacing the Remote Control Batteries............................18
Remote Control Operating Range................................19
Easy Interactive Pen (EB-536Wi only) . . . . . . . . ........................19
Replacing the Battery for the Interactive Pen.........................20
Replacing the Tip of the Interactive Pen............................21
Preparing the Projector
Installing the Projector ..................................... 23
Installation Methods...........................................23
Installation Methods.........................................24
When Using the Interactive Features (EB-536Wi only)...................24
Connecting Equipment ..................................... 26
Connecting a Computer ......................................... 26
Connecting Image Sources.......................................28
Connecting USB Devices .........................................30
Connecting a Microphone.......................................32
Connecting External Equipment...................................33
Connecting a LAN Cable .........................................35
Installing the Optional Wireless LAN Unit.............................36
Installing the Optional Quick Wireless Connection USB Key...............37
Connecting Multiple Projectors (EB-536Wi only).........................38
Basic Usage
Projecting Images ......................................... 41
Turning On the Projector........................................41
Turning Off the Projector........................................42
Automatically Detect Input Signals and Change the Projected Image (Source Search)
..........................................................43
Switching to the Target Image Using the Remote Control..................44
Projecting with USB Display......................................45
System requirements ......................................... 45
Connecting for the First Time...................................46
Uninstalling ...............................................47
Adjusting Projected Images ................................ 48
Correcting Keystone Distortion....................................48
Correcting Manually.........................................49
Correcting Automatically (EB-536Wi only)...........................52
Adjusting the Image Size ........................................ 52
Adjusting the Image Position.....................................52
Adjusting the Horizontal Tilt ......................................52
Correcting the Focus...........................................53
Adjusting the Volume..........................................53
Selecting the Projection Quality (Selecting Color Mode)...................53
Setting Auto Iris..............................................54
Changing the Aspect Ratio of the Projected Image.......................55
Changing Methods..........................................55
Contents
3

Epson EB-520 Specifications

General

Matrix size	0.55 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.5 - 1.3 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	50 - 108 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	15 °
Projector brightness (economic mode)	1600 ANSI lumens
Focus	Manual
Throw ratio	0.55:1
Focal length range	0 - 6.4 mm
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Microphone in	Yes
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	0
Noise level	35 dB
Country of origin	China
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	278 W
Power consumption (PowerSave)	219 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	490 mm
Package width	385 mm
Package height	210 mm
Package weight	5860 g
