Epson EB-S18 User Manual

Projecting images
a
Press the [ ], [ ], [ ], or [ ] buttons to select the file or folder
you want to project.
a
If not all of the files and folders are displayed on the current
screen, press the []] button on the remote control, or position
the cursor on Next Page at the bottom of the screen and press
the [
] button.
To return to the previous screen, press the [[] button on the
remote control, or position the cursor on Previous Page at the
top of the screen and press the [
] button.
b
Press the [ ] button.
The selected image is displayed.
When a folder is selected, the files in the selected folder are
displayed. To return to the previous screen, position the cursor on
Back to Top and press the [
] button.
Rotating images
You can rotate the played images in 90˚ increments. The rotating function
is also available during Slideshow.
a
Play images, or run Slideshow.
b
While projecting, press the [ ] or [ ] button.
Stopping PC Free
To close PC Free, disconnect the USB device from the USB port on the
projector. For devices such as digital cameras or hard disks, turn off the
device and then remove it from the projector.
Projection Functions
50

Epson EB-S18 Specifications

General

Resolution	SVGA (800 x 600)
Weight	2.4 kg
Projection System	3LCD Technology
Projection Ratio	1.45 - 1.96:1
Brightness	3000 lumens
Contrast Ratio	10000:1
Lamp Life	5000 hours (Normal), 6000 hours (Eco)
Connectivity	USB 2.0 Type A, USB 2.0 Type B, VGA in, HDMI in, Composite in, S-Video in
LCD Panel	0.55-inch
Keystone Correction	Vertical ±30 degrees
Zoom	Digital
Projection Size	30 inches - 300 inches
Projection Distance Tele	0.88 m - 10.44 m
Security	Kensington lock
Colour Modes	Dynamic, Presentation, sRGB, Blackboard
Power Consumption	270 Watt
Dimensions	297 mm x 234 mm x 77 mm (Width x Depth x Height)
