Epson EB-X14 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 48 Revision C
CN1105
RS Board
(EB-S11/X11
only)
--- ---
When pressing the power button, initialization starts normally, then the projection starts. But
the RS-232 cannot be used.
"Troubleshooting on Operation
Abnormality (p.41)"
CN1200 TH Board (1)
SE Sensor error
Sensor error occurs while initializing, and LEDs indicate the error, then the projector turns
into the abnormal stand-by status.
"Troubleshooting from the Error
Code on Cooling System Errors
(p.35)"
CN1201 TH Board (2)
CN1203 INT Fan
FN Fan error
Fan error occurs while initializing and LEDs indicate the error, then the projector turns into
the abnormal stand-by status.
CN1205 EX Fan
CN1206 Lamp Fan
CN3301 Speaker --- ---
When pressing the power button, initialization starts normally, then the projection starts.
Audio controller on screen display appears, but no sound is output from the speaker even if
the audio input is applied.
"TroubleShooting on Audio
Input/Output (p.40)"
Connector
No.
Destination
Error Information
Status Reference
Code Name

Epson EB-X14 Specifications

General

Native aspect ratio	4:3
Projection distance	1.1 - 10.8 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	±30 °
Projector brightness (economic mode)	2400 ANSI lumens
Focus	Manual
Throw ratio	1.48 - 1.77:1
Focal length range	17 - 20 mm
Lamp type	E-TORL
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
AC (power) in	Yes
Audio (L/R) in	-
Composite video in	0
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
RMS rated power	2 W
Noise level	37 dB
Preset modes	Dynamic, Presentation, sRGB, Vivid photo
Country of origin	China
Noise level (economic mode)	29 dB
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3964 g
