Epson EB-X14G Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 48 Revision C
CN1105
RS Board
(EB-S11/X11
only)
--- ---
When pressing the power button, initialization starts normally, then the projection starts. But
the RS-232 cannot be used.
"Troubleshooting on Operation
Abnormality (p.41)"
CN1200 TH Board (1)
SE Sensor error
Sensor error occurs while initializing, and LEDs indicate the error, then the projector turns
into the abnormal stand-by status.
"Troubleshooting from the Error
Code on Cooling System Errors
(p.35)"
CN1201 TH Board (2)
CN1203 INT Fan
FN Fan error
Fan error occurs while initializing and LEDs indicate the error, then the projector turns into
the abnormal stand-by status.
CN1205 EX Fan
CN1206 Lamp Fan
CN3301 Speaker --- ---
When pressing the power button, initialization starts normally, then the projection starts.
Audio controller on screen display appears, but no sound is output from the speaker even if
the audio input is applied.
"TroubleShooting on Audio
Input/Output (p.40)"
Connector
No.
Destination
Error Information
Status Reference
Code Name
