EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 80 Revision C
Polyimide tape=20x10mm (2 sheet putting)
Encompass the edge (Blue line part) and put tape.
Figure 3-22.
MA Plate
Polyimide tape
