Projection begins immediately by
simply connecting the projector to
a PC using the included USB
cable. It’s also possible to operate
the mouse and page up/down
between presentation pages with
the remote controller.
Frontal Exhaust
The exhaust is positioned in the front, so people sitting beside the
projector are not bothered.
USB Display
AV Mute Slide Lens Shutter
Mute is achieved easily by closing the slide cover. This is convenient
for situations like writing memos on the white board when using it as a
screen, or even when you want to take a short break.
EB-X7
Specification of LCD Size 0.55 inch (x 3)
Main Parts Pixel Number 786,432 dots (1024 x 768) x 3
Native Resolution XGA
Projection Lens Manual focus & 1.2x optical zoom
F=1.58 - 1.72 / F=16.9 - 20.28mm
Lamp Type 175W UHE
Life 4000 hours (High Brightness mode) / 5000 hours (Low Brightness mode)
Screen Size 30 to 300 inch [0.9 to 9.0m]
Offset 8:1
Light Output* Brightness Control Normal / Eco 2200 lm / 1960 lm
Color Light Output* 2200 lm / 1960 lm
Contrast* 2000:1
Sound Output 1W monaural
Analog RGB Input Terminal Video D-sub 15-pin x 1
Audio Stereo Mini x 1
Output Terminal Video D-sub 15-pin x 1
Audio Stereo Mini x 1
Video Input Terminal Video Composite Video: RCA (Yellow) x 1
S-Video: Mini DIN x 1
Component Video: D-sub 15-pin x1 (in common with Analog RGB connector)
RGB Video: D-sub 15-pin x1 (in common with Analog RGB connector)
Audio Stereo Mini x 1 (in common with Analog RGB Audio terminal)
Control Terminal USB Type B x 1
Operating Temperature 5°C to 35°C <41°F to 95°F>
Operating Altitude Up to 7,500 feet <2,286m> (over 4,921 feet <1,500m> area: with High Altitude mode)
Start-Up Period About 5 sec.
Direct Power On Yes
Cool-Down Period Instant off
Power Supply Voltage 100 - 240V AC +/- 10%, 50/60Hz
Power Consumption 100-120V Lamp on 244W
Stand by 0.3W (Communication Off)
220-240V Lamp on 234W
Stand by 0.4W (Communication Off)
Dimensions Exclude Feet (D x W x H) 228 x 295 x 77
Weight Approx. 5.1 lbs. / 2.3 kg
Fan Noise Brightness Control : Normal / Eco 34dB / 29dB
*Light Output / Color Light Output / Contrast --- Color mode: Dynamic, Zoom: Wide
SPECIFICATIONS
SUPPLIED ACCESSORIES
Power Cable 1.8m
Remote Control
With AA type alkaline batteries x 2pcs
Computer Cable
1.8m <6 ft>, AHD-15 pin type slim-cable
Storage Case
Password Protect Sticker
Owner’s Manual
OPTIONAL ACCESSORIES
ELPLP54 Spare Lamp
ELPAF25 Air Filter Set
CONNECTOR PANEL
1 Audio Out
2 Audio Input
3 S-Video Input
4 Video Input
5 USB (Type B)
6 Computer Input
7 Monitor Out
1
2
3
4
56 7
CONNECTOR PANEL PROJECTION DISTANCE (EB-X7)
4:3 Screen size
60˝ /
80˝ /
100˝ /
200˝ /
120cm × 91xm
160 cm x 120 cm
200 cm x 150 cm
410 cm x 300 cm
47.2˝ x 35.4˝
63.0˝ x 47.2˝
78.8˝ x 59.1˝
161.4˝ x 118.1˝
Y
(cm / inch)
Longest (Tele)
217 / 85
290 / 114
363 / 143
729 / 287
Z
(cm / inch)
10 / 4
14 / 5.3
17 / 6.7
34 / 13.3
Shortest (Wide)
180 / 71
241 / 95
302 / 119
607 / 239
X
(screen size / dimension)
Offset
Optical unit with high light-use efficiency
WARRANTY SERVICE
2 Years Onsite Warranty Service to
be provided for local purchase only.
# The warranty service can be extended by
purchasing Epson Coverplus Extended
Warranty.
For more information, please contact
Epson customer support.
Bold, Bright, Beautiful...
3LCD Technology
3LCD technology achieves bright, natural images
and smooth, sharp video playback. No color
break-up makes images gentle on the eyes.
AUG09-16-PROJECTOR
Epson Customer Service Centre
Unit 517, Trade Square, 681 Cheung Sha Wan Road,
Cheung Sha Wan, Kowloon, Hong Kong
20/F., Harbour Centre,
25 Harbour Road, Wanchai, Hong Kong
Enquiry hotline :
(852) 2827 8711
Technical hotline : (852) 2827 8911
URL: www.epson.com.hk
Epson Hong Kong Limited
20/F., Harbour Centre,
25 Harbour Road, Wanchai, Hong Kong
