Epson EMP-X5 Service Manual

4-2
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
4.1 Overview
This chapter describes the procedures for disassembling and assembling the main components
of the EMP-822/EMP-83/EMP-X5/EMP-S5 projector. Unless otherwise specified, reassembly
is the reverse of the disassembly procedure. Read the precautions described in the next section
before starting.
4.1.1 Precautions
Some procedures require specific precautions that must be followed, and those will be noted
throughout this chapter. Note the following precaution definitions:
WARNING
CAUTION
REASSEMBLY
CHECK POINT
W A R N I N G
Procedures which, if not strictly observed, could result in personal injury are
described under the heading WARNING
CAUTION signals a precaution which, if ignored, could result in damage to
equipment.
If assembly needs special attention or the procedure is different from the reversed
disassembly procedure, the correct procedure is described under the heading
REASSEMBLY.
C H E C K
P O I N T
Important tips for procedures are described under the heading CHECK POINT.

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
