Epson EMP-X5 Service Manual

4-24
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
4.3.4.3. Removing the Front Case/Rear Case
1. Remove the four screws (C.C.P-TITE SCREW,3X8,F/ZN-3C) that secure the Front Case
and the Rear Case, and remove the Rear Case from the Front Case.
2. Remove the screw (C.C.P-TITE SCREW,3X8,F/ZN-3C) that secures the Plate Nut, and
remove the Plate Nut from the Rear Case.
Figure 4-18.
Rear Case
Plate Nut
Front Case

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
