4.2.4 REMOVAL OF PRINTER MECHANISM
This section describes the removal of the platen unit, paper guide, and printer mechanism. The platen unit
and paper guide are removed first to enable quick and easy removal of the printer mechanism.
,,*
Figure 4-11. Printer Mechanism Removal
4.2.4.1 Removal of Platen Unit and Paper Guide
1. Remove the upper case (refer to Section 4.2.1.1).
2. Remove the cover of the paper tension unit.
(3 Open the cover
@ Pull out
Tension Unit Cover
Figure 4-12. Removal of Paper Tension Unit Cover
