Paper Handling 7
1
1
1
1
1
1
1
1
1
1
1
1
3. Facing the back of the printer, release the sprocket lock levers
by pushing them up.
4. Position the left sprocket so that the sprocket pins are to the
left of the arrow mark (0 position) on the back of the printer.
Then push down the lock lever to lock the sprocket in place.
Note:
Printing starts at the arrow mark (0 position) on the back of the
printer.The unprintable area is to the left of the arrow mark.
5. Slide the right sprocket to roughly match the width of your
paper, but do not lock it.
sprocket lock lever
