Epson PowerLite 1260 Installation Handbook

INSTALLATION
HANDBOOK
Maintenance
Epson PowerLite 1220 / 1260
2
4. Loosen the two screws holding the lamp in place (you can’t
remove them).
5. Hold the lamp as shown and pull it straight out.
6. Gently insert the new lamp. (If it doesn’t fit easily, make sure it is
facing the right way.) Then tighten its screws.
Loosen, but don’t
remove these screws
note
The lamp(s) in this
product contain mercury.
Please consult your state and
local regulations regarding
disposal or recycling. Do not
put in the trash.
7. Replace the lamp cover, then tighten its screw.
8. Reset the lamp timer as described in the next section.
note
Tighten the lamp cover
securely so you do not receive
a lamp cover error when you
turn the projector back on.

Epson PowerLite 1260 Specifications

Projection Specifications

projection system	Epson 3LCD, 3-chip technology
native resolution	1280 x 800 (WXGA)
white light output	2600 lumens
color light output	2600 lumens
contrast ratio	Up to 2000:1
color reproduction	16.77 million colors

Lamp and Lens

lamp type	200 W UHE
lamp life (ECO mode)	Up to 5000 hours
lamp life (Normal mode)	Up to 4000 hours
f-number	1.58 – 1.72
focal length	16.9 mm – 20.28 mm
zoom ratio	Optical zoom 1.0 – 1.2

Power and Operating Conditions

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	280 W
fan noise (Normal mode)	37 dB
fan noise (ECO mode)	29 dB
operating temperature	41° to 95°F (5° to 35°C)

Packaging Specifications

packaging dimensions	14.6" x 13.4" x 6.4" (W x D x H)
packaging weight	9.3 lb
genuine Epson lamp dimensions	6.3" x 5.6" x 5.6" (W x D x H)
genuine Epson lamp weight	0.7 lb
replacement air filter dimensions	4.8" x 3.5" x 1.9" (W x D x H)
replacement air filter weight	0.1 lb

Weight and Dimensions

dimensions including feet	11.6" x 9.0" x 3.1"
dimensions excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
