SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 88
SE Group Confidential (Related Staff Only)
Figure 3-9. Heater Mechanism
After Heater (p. 233)
Heats paper to dry ink after printing.
Cooling Fan (p. 235)
Cools the inside of the After Heater Box.
