EPSON Stylus Color 440/640/740 Revision A
Chapter 4 Disassembly and Assembly 105
4.2.1 Removing the Housing
Since the printer mechanism itself structures the bottom part, the printer
mechanism appears just by removing the housing.
1. Open the printer cover and turn the PG adjustment lever towards (+)
side.
2. Remove 4 screws (No.2) securing the housing, and remove the
housing.
Figure 4-2. Removing the Housing
CAUTION
Lift up and remove the housing, pulling it towards you.
(Since it collides with carriage)
(No.2)
Housing
