Epson Stylus Color 640 User Manual

EPSON Stylus Color 440/640/740 Revision A
Chapter 7 Appendix 171
Table A-22.
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
20H Password 2 5AH -
21H 0FH -
22H Interface selection 0: Auto, 1: Parallel
2: Serial
00H 00H
∗
2
23H Interface wait time 0 to 255 (by second) 0AH 0AH
24H Parallel I/F speed 0: High speed 1: Normal 00H 00H
25H Stylus Color 440
Reserved
00H -
Stylus Color 640
Font
0: Couier 00H 00H
26H Stylus Color 440
Reserved
00H -
Stylus Color 640
Pitch
0: 10 cpi 00H 00H
27H Stylus Color 440
Print direction
control
0: Bi-D
1: Uni-D
2: Auto
02H 02H
Stylus Color 640
Print direction
control
2: Auto 02H 02H
28H Stylus Color 440
CG table
0: PC437 1: PC850 00H (
∗
1)
Stylus Color 640
CG table
0: PC437 1: PC850 08H 00H
29H Reserved 00H -
2AH Auto LF/Network
I/F mode
bit1: Network I/F mode
(0=off, 1=on)
bit0: Auto line feed
(0=off, 1=on)
00H 00H
Table A-23.
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
2BH Panel mask
function
bit7: Enable Self Test
bit6: Enable Hex Dump
bit5: Extended settings
bit2: Cleaning
bit1: Replace I/C
bit0: Load/Eject
00H 00H
(*3)
2CH Reserved 00H -
2DH Reserved 00H -
2EH Reserved 00H -
2FH Reserved 00H -
30H Password 3 5AH -
31H 0FH -
32H Reserved 00H -
33H Reserved 00H -
34H Top margin 42 to 44X360
(by 1/360 inch)
78H 78H (*3)
35H 00H 00H
(*3)
NOTE
36H
37H
Stylus Color 440
Reserved
00H -
Stylus Color 640
Bottom margin
1244 to 44x360
(by 1/360 inch)
36H=F0H
37H=1EH
36H=F0H
37H=1EH
38H
Stylus Color 440
Reserved
00H -
39H Stylus Color 640
Page length
1244 to 44x360
(by 1/360 inch)
38H=F0H
39H=1EH
38H=F0H
39H=1EH
3AH Reserved 00H -
3BH Reserved 00H -
3CH Reserved 00H -
3DH Reserved 00H -
NOTE:
The reference *3 for the address 35H only applies to Stylus Color 440.
