EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
ADJUSTMENT Adjustment Except Adjustment Program 188
5. Click the “SGL” icon in the “EPSON Scanner Function Test - WriteZero for
service” window.
Figure 5-27. Original Adjustment (3)
6. Enter the product number in the “Single Test” window, select “Write Zero
Correction Value”, and press the [Execute] button.
Figure 5-28. Original Adjustment (4)
7. A progress bar will be displayed followed by the window shown below.
<Window displayed when the adjustment is completed successfully>
Figure 5-29. Window displayed when the adjustment is complete
d successfully (1)
Figure 5-30. Window displayed when the adjustment is complete
d successfully (2)
SGL Icon
Enter the last five digits of the scanner production
control number label, put one space, and then enter the
last five digits of the printer production control
Execute Button
Select “Write Zero Correction Value”.
To Next Page
