Epson Stylus Pro 3850 - Initial Ink Charge; Cleaning

Epson Stylus Pro 3800/3800C/3850/3880/3885/3890 Revision C
ADJUSTMENT Standard Adjustment 234
5.3.8 Initial Ink Charge
 Purpose
Carry out the initial ink charge.
 Procedure
1. Turn the printer ON.
2. Start up the Adjustment Program and select [Initial Ink Charge].
3. Press the F5 key to pop up a verification screen, and click [OK] to start the
initial ink charge.
4. When ink charge is completed, click [Finish].
Figure 5-35. [Initial Ink Charge] screen
5.3.9 Cleaning
 Purpose
There are four types of head cleaning. Select and run a one of them to clean the
print head.
 Procedure
1. Turn the printer ON.
2. Start up the Adjustment Program and select [Cleaning].
3. Select the cleaning type and press the corresponding key (F1 to F4) to run the
selected cleaning.
4. When the cleaning is completed, click [Finish].
Figure 5-36. [Cleaning] Screen
F5
Key Cleaning
F1 CL1
F2 CL2
F3 CL3
F4 CL4
