Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
DISASSEMBLY & ASSEMBLY Parts Diagram 190
Confidential
Figure 4-7. Carriage Mechanism
CR Motor
(p242)
CR Scale
(p236)
CR Encoder Sensor
(p238)
CR HP Sensor
(p239)
APG Motor
(p243)
APG Unit
(p244)
Driven Pulley Unit
(Contain the CR Timing Belt)
(p240)
PG HP Sensor
(p246)
Carriage Unit
(p248)
