EN
10
It is prohibited to install and to use TYPHOON fan with the terminal box
facing down.
The level of inclination of the TYPHOON fan terminal box should not be
lower than the central axis.
1
1. Disconnect power supply.
2. Open the clamp by pulling the tab upwards.
3. Remove the fan casing from the base.
4. Attach the base to the mounting surface and mark the screw hole.
5. Drill holes; fix the fan base to the mounting surface with screws.
6. Install the body by tightly connecting the clamp.
TYPHOON fan installation instructions:
Figure 2aFigure 3a
