1 Locate a wall stud. Place the bracket
against the wall using a level to make
sure it’s aligned, and mark the screw
holes. Remove the bracket.
2 Pre-drill pilot holes into a stud using a
9/64” drill bit. Place the bracket
against the wall with the small arrows
pointing up, and secure it to the wall
with 2 long wall bracket screws
(included) and a power drill or
Phillips-head screwdriver.
3 Remove the screw from the mount
assembly. Rotate the mount 180
degrees so the screw holes are facing
up, then reattach the screw to the
mount assembly.
