ERGOPIXEL GD-0003 - Finalizing Baffle and Wiring

Install the baffle (7) on both side of the supporting
beam (4) with the screws (B), and then use 2.5*2.5
allen key (A) to tighten.
9
11
8
AC
H S
M1
D C
Power Port
Port for cable
connected to
the lifting column
Port for
handset
Assembly Video:
