WELCOME
Thank you for purchasing the Dock
Locker for Microsoft Surface Pro 3
Docking Station.
If you have any questions or if we can
help you in any way, please contact us
at 800.325.3841.
TOOLS
A power drill and drill bit (either 1/4"
or 1/8" depending on your installation
method) may be required for this
assembly.
A Phillips screwdriver and 3/8" socket or
nut driver may also be required.
These tools are included with your
shipment:
5/32" hex driver bit
5/32" hex Anthro driver
3-way wrench
PARTS LIST
Before beginning installation of your Dock Locker, please
review the parts list to verify that your shipment is complete.
The fastener quantities listed are the minimum required to
complete the installation. Your shipment may have included
extras.
2
Product Quantity Part Number
01 Locker Assembly 1 835-MLD
A. Top Cap 1 225-4931-00
B. Bottom Plate 1 225-4957-00
02 #10-24 x 2.5" Bolt 2 325-5747-00
03 #10-24 Nylock Nut 2 325-5186-00
04 #10-9 x1" PB Screw (not shown) 2 325-5580-00
KEYS
For replacement keys, order part number
979KY.
01
02
03
A
B
To Next Page
