Fig. 1
Always wear protective safety glasses and gloves
while working with CADWELD
®
exothermic products.
Fig. 2
Prepare the proper materials and equipment for the
type of connection you are making. The CADWELD
®
PLUS system requires a graphite mold, mold clamp,
CADWELD PLUS welding material cup, natural bristle
brush for mold cleaning, wire brush for cleaning/
preparing conductors, control unit, and propane torch.
NOTE: Additional materials may be required
for your specific application. Refer to your
mold instructions. Advise nearby personnel of
welding operations in the area prior to ignition.
Fig. 3
Check to ensure the graphite mold is not worn or
broken, which could cause leakage of molten weld
metal during the reaction.
The CADWELD
®
PLUS Process
11
