ERICO Eritech Cadweld - Control Unit and Ignition Strip Connection

Fig. 16
Place the cup into the top of the mold. Make sure
the ignition strip nests into the recess on the top
edge when the cover is closed.
Fig. 17
Battery powered control unit.
Fig. 18
Place the ignition strip into the control unit
connector. Remove or protect fire hazards in
close proximity to the connection.
16
The CADWELD
®
PLUS Process
