Fig. 16
Insert the steel disk (concave side up) into the mold.
Hold the steel disk on the side of the mold and let it
slide into place.
Fig. 17
Ensure that the steel disk is properly seated.
Fig. 18
Next, take a tube of properly sized welding material
(as identified on the mold ID tag) out of the box.
