Web GUI Control
Parameter Values Description
Adaptive
Preprocessing
Off, On
Increases the video quality by performing preprocessing
operations. Available only if Video Input Format is set to
SD 480i29.97 or SD 576i25.
Bandwidth 30 to 100 % Sets the video horizontal bandwidth filter.
Half Line Removal Off, On
Enables or disables the removal of black half lines at the
top of the picture by substituting video data from adjacent
lines. The option is available when Video Input Format is
set to SD 576i25.
Logo
Logo insertion Off, On
Controls if logos are displayed or not. The file to use can
be selected under Logo file.
Logo file
The file to use as a logo. The selected file can be
uploaded by selecting the Upload option. Not supported in
this release.
A fixed logo position? On, Off
Controls whether to use the default position for overlaying
the logo on the video. If On, the position of the logo is fixed
according to the position held within the logo file. If O ff,
the position of the logo is determined by the coordinates
entered in the X and Y position boxes.
The X position of the
logo
The position relative to left of the screen 0 (number of
pixels per video line - logo width - 1). If an invalid position
is specified, a logo display alarm will be generated.
Displayed only if A fixed logo position? is set to Off. Not
supported in this release.
The Y position of the
logo
The position relative to top of screen 0 (number of video
lines - logo height - 1). If an invalid position is specified, a
logo display alarm will be generated. Displayed only if A
fixed logo position? is set to Off. Not supported in this
release.
HD to SD Video Down-conversion
Default Aspect Ratio
Conversion
Anamorphic, Center Cut, Letterbox
The down-conversion to apply when AFD is lost or AFD
code 000 is received.
Use Input AFD true, false
Specifies whether to attempt to use AFD code at input for
format conversion (when true) or always apply the default
(when false).
Action on AFD lost
Convert as anamorphic and put AFD code 1000
out, Convert as specified in Default and put AFD
code out
Specifies what to do if AFD is lost.
Action on AFD code
0000
Convert as anamorphic and put AFD code 1000
out, Convert as specified in Default and put AFD
code out
Specifies what to do if AFD code 0000 is received.
Video Encoding
The parameters listed below are available on the Encode tab of the Properties widget on
the Service Configuration page when a video component is selected in the Outputs
widget. The same parameters can be accessed through the Advanced/CE-a/Video/Video
1/Video/Main Video/Video Encoder menu on the front panel.
