Löt- und Gasgeräte GmbH
Bahnhofstraße 50, D-74254 Offenau
Tel. +49 7136 9594-0
Fax +49 7136 9594-44
Internet: www.cfh-gmbh.de
E-Mail: info@cfh-gmbh.de
Stand: VO-07.14
A At first fill the device with the supplied gas for lighters as shown
on the picture. Press (pump) the cylinder several times at the
gas filling valve.
B Flame adjustment: When igniting the device position the flame
adjustment lever in the middle between min. È and max. Å.
With the flame adjustment lever you can adjust the flame length
(small/big). You can adjust the length of the flame during the
use by moving the flame adjustment lever (picture B) back and
forth. Sliding towards Å causes a stronger flame, towards È a
weaker flame.
C Release the safety latch of the piezo ignition: Simply push
down the red safety latch, which is under the piezo ignition
button, and release it.
D Ignite: Press now piezo ignition button and hold it.
Attention: The piezo ignition button (picture D) can be pressed
only if the red release safety latch (picture C), which is
underneath, has been pushed down. Note: If the piezo ignition
button (picture D) is not pressed in correctly, the safety latch
(picture C) springs up immediately and it is not possible to
press the ignition button or to ignite the device. If this happens
start the ignition process from the beginning!
E Continuous flame: Hold the piezo ignition button pressed and
at the same time slide the red continuous flame lever (as the
black lower arrow indicates in picture E) to the position LOCK
ready. The flame of the device burns now continuously.
F Switch off the device: To extinguish the flame, simply release
the piezo ignition button. If the continuous flame lever is in
position LOCK, slide it into the OFF position (see picture F).
The device is switched off.
Storage and transportation
After end of work and before storage ensure that the device has cooled
down completely (at least 20 minutes). Afterwards you can store it in a
secure and dry place. For transport make sure that the device has cooled
down completely. Ensure that the Culinary Torch is secured during
transport.
Cleaning the device
To clean the device, wait until the burner has cooled down and use a
dry cloth. Do not use any cleansing agents because the openings in the
burner and the nozzle could become blocked.
Care of the device + maintenance
Use only recommended spare parts. Do not use a device where any
parts are damaged. Any repairs, as well as replacement of the nozzles,
must be carried out only by an authorized specialist dealer for liquid gas
or the manufacturer/distributor. In case of repair please contact the
manufacturer under the address stated below.
Do not change settings of the device or make modifications from those
set by the producer. It could be dangerous to change the structure of
the device on your own authority, to remove parts or to use parts which
are not approved by the manufacturer/distributor.
Service Address & Manufacturer:
Ignition/Adjustment of the flame Warranty
You are granted a two-year warranty for this device as of the date of
purchase. The warranty period starts on the date of purchase. Please
keep the original sales receipt for further reference. The receipt will be
required as a proof of purchase. If a material or manufacturing fault
appears within 2 years as of the date of purchase of this product, CFH
will, at its discretion, repair or replace this product free of charge. This
warranty will only be granted within two years provided the defective
device and the purchase of evidence (sales receipt) is presented as well
as a short written description stating the character of the defect and time
when it appeared. After the defect has been resolved through our
warranty, you will get the repaired or the new product back. No new
warranty period is granted with repair or replacement of the product.
In case of a warranty claim, please contact us by e-mail under info@cfh-
gmbh.de. We will get in touch with you immediately.
Environmental instructions
The liquid gas used is environmentally friendly, which does not burden
or damage the environment and it is not dangerous for the ozone layer.
Follow the regulations for the liquid gas. The refill cylinder or its contents
do not have a restricted shelf-life.
Disposal of the refill cylinder
Emptied gas cylinders can be disposed of through using the waste
recycling system. Not fully emptied gas cylinders have to be disposed
of at collection centres for harmful substances.
Disposal of the device
The device is produced of recyclable materials. To dispose of or to
recycle this device, get in touch with an authorized local Recycling Office
or a waste disposal company.
We hope the Culinary Torch CB 90 will be a useful and reliable helper
in your kitchen for many years.
Technical data
Consumption: appx. 44 g/h
Nominal heat load/capacity: appx. 0,60 kW
Ignition system: piezo ignition
Gas type: mixture of propane/butane
The power rating in the instructions for use are values which had been
measured under laboratory conditions (according to DIN EN 521 5.19).
It is possible to measure other consumption data when using the device
with the propane/butane refill. (Important information: The ambient
temperature has an essential influence on the performance of the device.
As a general rule is that the performance decreases at low temperatures).
Technical and optical parameters are subject to change.
C
Release safety latch
Picture A
Filling
Picture B
Flame adjustment
Picture F
Switch off the device
D
Ignition
E
Continuous flame
