Validity
This manual covers the following keyboards:
Keyboard type 1500M, 1501M, 1502M or 1503M software version 1.1 Release
17.08.98 or later.
Compatibility
The Series 1500 keyboards are compatible with the following equipment:
SYSTEM 500M/1000M
1501M/1503M: Software Version 4.1 Release 10.03.97, or later.
1502M: Any version; however the Adpro functions are available only when
supported by the matrix software.
1500M: Any version.
Series BDR-510 telemetry receiver, software V.1.0 Release 05.11.96, or later.
Series BDR-550 telemetry receiver, software V.2.0 Release 16.10.96, or later.
BDR-575 telemetry receiver, software version 1.0 Release 13.03.97, or later.
Integrated Camera Unit (ICU), software version 1.0.
Approvals
All keyboard types are CE certified and approved with respect to EN 50081-1 and EN 50130-4
(EMC) and EN 60950 (LVD).
Introduction
The keyboards Series 1500 can be used for operating SYSTEM 500M and SYSTEM 1000M as
well as for direct operation of telemetry receivers Series BDR-510, Series BDR-550, BDR-575
and Integrated Camera Units (ICU).
However, variable speed operation of BDR-575 and the ICU is only possible when used with
keyboard 1501M or 1503M.
Keyboard types
Keyboard 1500M is equipped with a serial port with selectable RS-232/RS-485
interface.
Keyboard 1501M is furthermore equipped with a joystick for variable speed
operation of BDR-575 and the ICU.
Keyboard 1502M is equipped with a serial port with selectable RS-232/RS-485
interface and an ARC-net port for connection to SYSTEM 500M and 1000M. A
LCD display with two lines of each 40 characters and back light illumination are
used as status display and for user messages. The keyboard features Site selection
and Macro functions and is able to control the Adpro integration features in
connexion with SYSTEM 1000M, and SYSTEM 500M. For further information on
these subjects, refer to the SYSTEM 500M/1000M User- and Programming
Manuals.
Keyboard 1503M is furthermore equipped with a joystick for variable speed
operation of BDR-575 and the ICU.
Unpacking the keyboard
After unpacking the keyboard, carefully check for any sign of damage. Any such damage
should be reported to your supplier, or to Ernitec A/S directly, before installation.
Check that the keyboard packing carton contains the following items:
1 Keyboard 1500M, 1501M, 1502M or 1503M.
1 Keyboard Installation Manual (this manual)
1 Connector kit
1 Power supply
Installation and Setup instruction for Keyboard Series 1500
Page 2
