ESAB fabricator 141i Service Manual

ESAB FABRICATOR 141i
DISASSEMBLY PROCEDURE 7-8 Manual 0-5448
7.07 Base Panel Removal and Main PCB1 Disassembly
!
CAUTION
Read and follow safety information in Section 6.02 before proceeding with disassembly.
1. Remove Wire Feeder Screws.
2. Remove Inductor Screws.
3. Remove Central Panel Screws.
4. Remove Main PCB1 assembly Screws.
5. Remove Rectifiers.
6. Remove the feet of Main PCB1 assembly.
7. Heatsink on Main PCB1 assembly.
8. Main PCB1 assembly.
