HARDWARE IDENTIFIER
(To Scale)
H1 - 3.5 mm x 35 mm
Phillips Round
Head Screw
(8 pcs)
(Not to Scale)
H3 - 3.5 mm x 14 mm
Phillips Round
Head Screw
(8 pcs)
H7 - 8 mm x 38 mm
Allen Head Bolt
(8 pcs)
H10 -
M4 x 27 mm Phillips
Round Head Bolt
(26 pcs)
H11 - M4 Nylock Locknut
(26 pcs)
H8 - 8 mm x 50 mm
Allen Head Bolt
(8 pcs)
H4 - 6 mm x 50 mm
Allen Head Bolt
(8 pcs)
H5 - 8.5 mm x 22 mm
Flat Washer
(16 pcs)
H2 - 3.5 mm x 18 mm
Head Screw
H9 - 3.5 mm x 12 mm
Phillips Flat
Head Screw
(4 pcs)
Allen Wrench
(1 pc)
(Not to Scale)
T2 - M5 Allen Wrench
(1 pc)
H6 - 6.5 mm x 16 mm
Flat Washer
(8 pcs)
Phillips Flat
(4 pcs)
T1 - M4
